POLYNEXPET

Material: Polyester
Specific Gravity: 1.38 (Sinking)
Key Properties:
- Excellent abrasion resistance
- Excellent fatigue resistance from repeated loading
- Good UV and chemical resistance
- Maintains 100% tensile strength when wet

Applications: Mooring line, Anchor line, Tug line
Size			Weight		Breaking strength		Breaking strength
Dia(inch)	Cir(inch)	Dia(mm)	220m(kg)	60Oft(Ib)	ton	kN	ton	kN
1-1/8	3-1/2	28	136	249.00	16.00	157	16.32	160
1-5/16	4	32	170	311.00	21.00	206	21.30	209
1-7/16	4-1/2	36	210	385.00	26.00	256	26.40	259
1-5/8	5	40	260	476.00	32.00	315	33.40	328
1-3/4	5-1/2	44	310	568.00	38.00	373	38.40	376
1-15/16	6	48	370	678.00	46.00	452	46.50	456
2-1/8	6-1/2	52	434	795.00	54.00	530	54.60	535
2-1/4	7	56	505	925.00	62.00	609	62.75	615
2-3/8	7-1/2	60	580	1063.00	73.00	716	73.80	723
2-1/2	8	64	660	1209.00	83.00	814	83.90	822
2-718	9	72	840	1539.00	104.00	1020	105.00	1029
3-1/4	10	80	1020	1869.00	127.00	1246	128.00	1255
3-1/2	11	88	1240	2272.00	152.00	1492	152.00	1502
3-3/4	12	96	1480	2711.00	182.00	1778	182.50	1788
4-1/8	13	104	1740	3188.00	209.00	2040	209.60	2054
4-12	14	112	2020	3701.00	244.00	2385	244.70	2398
4-3/4	15	120	2310	4232.00	279.00	2730	280.80	2752
5-1/8	16	128	2600	4763.00	295.00	2895	296.50	2906
5-3/8	17	136	2945	5395.00	314.00	3076	315.00	3088
5-11/16	18	144	3286	6020.00	327.00	3219	329.20	3226
6	19	152	3673	6729.00	346.00	3385	347.00	3400
6-3/10	20	160	3980	7291.00	363.00	3560	366.00	3588

***±5% tolerance according to ISO2307
