POLYNEXPA

Material: Polyamide (Nylon)
Specific Gravity: 1.14 (Sinking)
Breaking Elongation: 35%
Melting Point: 220°C
Key Properties:
- Excellent Abrasion Resistance
- Excellent Shock Absorption
- Good Chemical and Corrosion Resistance

Applications: Mooring line, Tug line, Offshore, Other industrial heavy-duty use
Size			Weight		Breaking strength		Breaking strength
Dia(inch)	Cir(inch)	Dia(mm)	220m(kg)	60Of(Ib)	ton	kN	ton	kN
1-1/8	3-1/2	28	107	196.00	18.00	177	19.00	188
1-5/16	4	32	139	255.00	27.00	226	28.60	280
1-7/16	4-1/2	36	176	322.00	29.00	285	30.70	301
1-5/8	5	40	218	399.00	35.00	345	36.50	358
1-3/4	5-1/2	44	264	484.00	42.00	412	43.50	426
1-15/16	6	48	321	588.00	48.60	476	51.50	504
2-1/8	6-1/2	52	365	669.00	56.80	556	59.40	582
2-1/4	7	56	425	779.00	64.00	628	66.00	650
2-3/8	7-1/2	60	486	890.00	72.00	708	75.00	736
2-12	8	64	554	1015.00	82.70	810	84.50	828
2-7/8	9	72	702	1286.00	102.00	1002	105.00	1030
3-1/4	10	80	867	1588.00	125.00	1228	128.60	1264
3-1/2	11	88	1049	1916.00	149.00	1452	160.00	1568
3-314	12	96	1250	2290.00	173.00	1698	185.00	1815
4-1/8	13	104	1465	2684.00	205.60	2015	221.00	2168
4-12	14	112	1698	3111.00	225.50	2210	251.00	2464
4-3/4	15	120	1950	3572.00	259.00	2530	288.00	2826
5-1/8	16	128	2220	4067.00	297.00	2910	333.00	3260
5-3/8	17	136	2510	4598.00	324.50	3180	364.00	3568
5-11/16	18	144	2820	5166.00	364.00	3570	403.00	3950
6	19	152	3146	5763.00	400.00	3920	447.00	4380
6-3/10	20	160	2476	4536.00	437.00	4280	478.00	4680

***±5% tolerance according to ISO2307
