English- Material: UHMWPE Core with Polyester Sheath
- Specific Gravity: 1.01 – 1.09 (Near-Neutral Buoyancy)
- Breaking Elongation: 5%
- Melting Point: 150°C (UHMWPE Core) / 265°C (Polyester Sheath)
- Key Properties:
- Superior Abrasion Resistance
- Excellent UV & Chemical Resistance
- Tensile Strength Unaffected by Water
POLYNEXUHMWPE -D
POLYNEXUHMWPE -D
Description
POLYNEXUHMWPE-D is a double-braided rope engineered for exceptional performance in demanding marine and industrial applications. It combines a high-strength, 12-strand UHMWPE core with a protective, high-toughness polyester sheath, available in 24, 32, or 48 strands to meet specific operational requirements.
This innovative hybrid construction delivers a superior combination of properties that make it an outstanding choice:
- Enhanced Durability: Delivering higher wear and UV resistance than standard UHMWPE ropes for extended service life in harsh environments.
- Superior Load Management: Featuring reduced stretch and creep for maintained tension and precise load control.
- Increased Safety Assurance: Providing greater operational safety through reliable performance under demanding conditions.
- Optimized Construction: Leveraging the strength of UHMWPE with the protective qualities of polyester for balanced performance.
Specifications
|
Applications: Mooring line, Tug line, Super-sized commercial vessel, Wire rope replacement |
|||||||
|
Size |
Linear density |
Weight |
Breaking strength |
||||
|
BS(Yarns T/S-41g/d) |
BS(Yarns T/S-32g/d) |
||||||
|
Cir(inch) |
Dia(mm) |
ktex |
220m(kg) |
ton |
kN |
ton |
kN |
|
3-1/2 |
28 |
490 |
116 |
76.20 |
748 |
52.20 |
562 |
|
4 |
32 |
621 |
148 |
91.20 |
895 |
68.50 |
671 |
|
4-1/2 |
36 |
767 |
182 |
107.30 |
1052 |
80.40 |
789 |
|
5 |
40 |
868 |
206 |
131.00 |
1285 |
98.20 |
964 |
|
5-1/2 |
44 |
955 |
227 |
157.00 |
1540 |
118.00 |
1158 |
|
6 |
48 |
1137 |
270 |
185.00 |
1815 |
139.00 |
1364 |
|
6-1/2 |
52 |
1342 |
295 |
212.00 |
2080 |
159.00 |
1560 |
|
7 |
56 |
1547 |
368 |
246.00 |
2408 |
184.00 |
1805 |
|
7-1/2 |
60 |
1784 |
392 |
265.00 |
2599 |
199.00 |
1952 |
|
8 |
64 |
2021 |
480 |
296.00 |
2903 |
222.00 |
2178 |
|
9 |
72 |
2598 |
617 |
365.00 |
3580 |
274.00 |
2688 |
|
10 |
80 |
3195 |
773 |
444.00 |
4355 |
333.00 |
3266 |
|
11 |
88 |
4450 |
1060 |
519.00 |
5090 |
390.00 |
3825 |
|
12 |
96 |
5700 |
1350 |
606.00 |
5943 |
455.00 |
4463 |
|
13 |
104 |
7670 |
1688 |
695.00 |
6810 |
520.00 |
5096 |
***±5% tolerance according to ISO2307
Ready to Engineer Your Solution?
We specialize in custom-engineered synthetic fiber ropes, tailored to your unique applications, load requirements, and environmental conditions. As a trusted manufacturer, we offer a wide range of constructions—from 3 to 48 strands and double braids, with diameters from 3 mm to 280 mm—to deliver reliable solutions for the most demanding scenarios.
